Color configuration
High brightness Dynamic White LEDs with an adjustable colour temperature range between 2700K and 6500K
Optical configuration
12° SP (Spot)
15° NB (Narrow)
25° MB (Medium)
45° WB (Wide)
58° EW (Extra wide)
40°h x 14°v ELH (Elliptical)
38°h x 23°v ELWH (Elliptical Wide)
35°h x 19°v (5° incline) WW (Wall Wash)
Max. Delivered lumen output
Up to 10.440 Lumens
Max. lumen/Watt
Up to 111 Lumens per Watt
Amperage
0.77 A @ 120VAC, 0.33 A @ 277VAC
Ingress protection rating
IP67
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
Five Year Limited Warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility and to be ordered separately.
